TW5382 Smart GNSS Antenna for High Accuracy Timing – Preliminary

More Products

The TW5382 is a multi-band, multi-constellation integrated GNSS receiver/antenna designed specifically to meet the strictest timing synchronization requirements in 5G mobile networks.

The state of the art GNSS receiver supports concurrent tracking of all four major constellations in multiple frequency bands. The multi-band capability reduces timing errors under clear skies to less than 5ns without the need for an external GNSS correction service.

The integrated dual feed Accutenna™ greatly improves the rejection of multi-path signal interference.

The TW5382 offers an optional master and slave configuration that features a differential timing mode that exchanges correction data with a neighboring TW5382 timing receiver via a RS-485 communication link. Under optimal conditions the timing accuracy can be further improved to less than 2.5ns.


Features

  • High mproved noise immunity with multi-band GNSS receiver
  • Improved multi-path rejection with Dual feed Accutenna™
  • Multi-band GNSS receiver is unaffected by ionospheric errors
  • High reliability timing with expansive constellation array
  • Exceptional timing performance without correction services
  • T-RAIM to support the highest level of timing integrity
  • Broad 5V-36V operation
  • RS-485 differential signalling
  • Industrial grade IP67 enclosure
  • Rugged fixed mount
  • Multipe cable lengths (5m, 15m, 25m)
  • Available with conical radome


Details


Concurrent Multi-band Access

The 5382 is designed to meet the strictest timing synchronization requirements in 5G mobile networks on a global scale. The concurrent multi-band access to all four satellite constellations improves the receiver’s capability to deliver a precise and reliable solution which is unaffected by ionospheric errors.

Less than 5 ns error

The TW5382 timing module’s multi-band capability reduces the timing error under clear skies to less than 5 ns without the need for an external GNSS correction service.

Differential comparison for <2.5 ns error!

The TW5382 offers an optional master and slave configuration that features a differential timing mode that exchanges correction data with a neighboring TW5382 timing receiver via a RS-485 communications link. Under optimal conditions the timing accuracy can be further improved to less than 2.5 ns error.
