TW5340 Multi-Constellation Smart GNSS Timing Antenna

More Products


The TW5340 is a multi-constellation GNSS Smart Antenna which provides simultaneous GPS/GLONASS/SBAS reception. It is designed for use in professional grade applications such as precision timing, network synchronization, low current applications, and tracking/positioning applications. The multi-band capability reduces timing errors under clear skies to +/- 25 ns.

The TW5340 GNSS Smart Antenna uses the state-of-the-art ST STA8088 receiver which provides 32 high sensitivity tracking channels plus 2 fast acquisition channels which can be assigned to acquire and track GPS, GLONASS, QZSS, and SBAS (WAAS, EGNOS, MSAS) signals simultaneously. The TW5340 employs Tallysman’s AccutennaTM dual feed antenna patch technology which greatly improves rejection of multi-path signal interference, across the whole GNSS band, making the TW5340 the most precise smart antenna in its size across all operating environments.



Features

  • Multi-Constellation Receiver/Antenna
  • 32 Channel simultaneous operation
  • High performance tracking (-162 dBm)
  • WAAS, EGNOS & MSAS enabled
  • 3 NMEA 0183 output lists
  • Navigation rates 1 to 10 Hz
  • 1 PPS & NMEA configurable RS422 outputs
  •  Low Current Standby Mode
  • Accutenna™ Technology
  • Excellent multi-path signal rejection
  • Industrial grade IP69K enclosure
  • RoHS, REACH and RED Compliant CE Marking


Details


The Best Antenna

The TW5340 employs Tallysman’s AccutennaTM dual feed antenna patch technology which greatly improves rejection of multi-path signal interference, across the whole GNSS band, making the TW5340 the most precise smart antenna in its size across all operating environments.

Rapid Fix

The TW5340 accelerates GPS positioning by predicting satellite ephemeris data based on previous observations, resulting in extremely fast Time-To-First-Fix.

Flexible interfacing

The TW5340 can be configured to output up to three NMEA 0183 message lists with navigation update rates up to 10 Hz. RS232 and CMOS interfaces are available with input voltage options of 3.3V, 5.0V and 12V to 36V with over voltage protection.

A standard on pulse-per-second signal (1PPS) synchronized to UTC time is available as a single -ended output or as a differential output at RS422 levels. NMEA data can also be configured to output at RS422 levels, however the 1PPS output is disabled in this mode.

Simple Configuration

Tallysman’s Windows™ based Configurator enables simple configuration of parameters such as baud rates, output message rates, constellation, tracking parameters, 1PPS configuration and Standby mod parameters. A non-magnetic version is available with Part Number TW5341.
